Sound Portals (soundports) for Classical Guitar

11

The theme of this week is “Instruments & Design

My experience with soundports: Sound portals are a bit strange at first because you’ll hear a whole new range of overtones, not to mention a huge volume increase while you play. However, I find it a bit odd because who ever hears a guitar that close? It’s like putting your ear right next to the sound hole. Nevertheless, when I owned my Stephen Connor guitar that had a portal I loved it for chamber music so the other musicians such as pianist’s could hear me. Since the portal projects sound in a direction other than straight toward the audience, everyone on stage could hear me. However, this often made me feel as if I was playing way too loud all the time. Some observers in audiences have commented on increased volume when I opened the portal but I suspect this aspect is minimal at best. Maybe sound waves bounce around the room a bit more in different directions.

Maybe the best reason to have a sound portal is that it gives you a confidence boost. It might deceive you too, making you think you are playing loud when in fact you are not. However, it sure can be nice if you’re practicing in a dead sounding room.

Recommended: If you decide to get a soundport I recommend getting one with a magnetic cover so you can choose whether it remains open or closed. See the picture of Dominelli’s cover.

Please note: The quotes below are brief and therefore often a bit out of context so follow the source link and read what the luthier or player has to say.

Stephen Connor (luthier) on Sound Portals:

The sound portal is something that I have been experimenting with for years, the prototype developed in the 90’s. It consists of an elliptical opening in the side of the guitar facing the player which increases the volume of the instrument to both the player and the audience by reducing the cancellation of sound waves making the instrument more efficient. It can be closed, partially or fully, with a door that is held on using magnets. Closing the portal can be advantageous during duets with a quieter instrument. The bracing patterns developed in tandem with the portal feature interlocking braces of the highest quality-bracing stock. This system creates a guitar that is exciting to play, extremely RESPONSIVE, with amazing volume and all the tonal colors found in the finest traditional guitars-perhaps even more…. from Connor Guitars

Photo via Connor Guitars

Connor's Sound Portal

Connor’s Sound Portal

Fritz Mueller (luthier) on soundports:

Acoustic ports function something like the soundhole in that they work in partnership with the inner air resonances of the instrument to release sound from the instrument. But the sound that comes from the port is primarily (if not entirely) for the player’s benefit, allowing the player to hear the sound of the guitar more completely. In modern, highly projecting guitars, this is particularly beneficial.

Acoustic ports on the sides near the neck have little or no effect on the sound that the audience hears at the front of the guitar. This is perhaps surprising and somewhat counterintuitive, as most people (myself included) initially think that there would be a loss of sound. This is easy to test, however, by covering and uncovering the acoustic port while playing. via Fritz Mueller’s website

Photo via Fritz Mueller’s website

Mueller Soundport

Mueller Soundport

Marcus Dominelli on Soundports

Soundports help the player hear the guitar, obviously. This can be useful in ensemble situations, on stage, or if the player simply wants to hear more of the guitar.

Good concert guitars are built to project the sound outward, and sometimes this can compromise the  “near field” sound. Soundports can help compensate for any near field weakness. Guitars made with really thin sides, like those built on a Torres design, do not really need a soundport, because the sides are so thin that they already resonate quite a lot of sound toward the player. Guitars with thicker solid sides, laminated sides, or that have a laminated back, will sound better to the player with a soundport.

I decided to make my soundports available with a magnetically fitting cover, so that the player can fine tune the amount of sound coming out. Fully open, ports can sometimes be too loud or distracting to the player, so it’s nice to be able to fine tune the sound by sliding it to the desired openning. This photo shows the port half covered. via Dominelli Guitars

Photo via Dominelli Guitars

Dominelli Soundport with Cover

Dominelli Soundport with Cover


In perspective:

Peter Oberg (luthier):

In the last ten years I’ve built at least 60 guitars with sound ports in them, which clearly suggests that I believe in them. There is no empirical evidence that ports in the sides bleed sound away from the soundhole. You have to remember that there is also sound coming off of the top, not just out of the soundhole. My personal instruments will always have ports-I can’t imagine not having them. It’s kind of like high speed internet in that way. via Peter Oberg via Delcamp

Alan Carruth (luthier):

The overall result was that opening a port seemed, in my tests, to give perhaps a 1-2% increase overall in power. This is not much: it takes a near doubling of power for a sound to seem twice as loud if the spectrum remains unchanged. Interestingly enough, the amount of the volume change did not seem to vary much with increasing port size. Apparently the broad band decrease tends to balance out any narrow band increases.

Since our ears are set up to detect changes (things that don’t change, like rocks, won’t eat you, and you can’t eat them, so why bother?) people in listening tests will often react very strongly to the opening of a port. The immediate impression is that the guitar is much louder. However, once they get used to the change, people are not so sure. We’re going to do some more testing on that one soon, I hope. via Alan Carruth on Delcamp [follow this link for a pretty big comment by Alan with lots of info…]


Have you read this?

I found this abstract and citation via liutaiomottola.com, if anyone has read the article leave a comment below.

Abstract
A blind listening evaluation of classical guitar soundports was performed to ascertain whether players could hear the difference between an instrument with an open port and the same instrument with a closed port, all in a context that is representative of a player’s instrument selection decision. The study was conducted to comply with the specifications detailed in standard ASTM E 2139-05, Standard Test Method for Same-Different Test from ASTM International (formerly called the American Society for Testing and Materials). Twenty four guitar player subjects were recruited to play a single guitar twice while blindfolded. In each of these two trials the open/closed port configuration of the guitar was selected at random. After playing the instrument in each port configuration the subject was asked to indicate whether there was or was not a difference heard between the two configurations. Results of this experiment indicate that the port open and port closed states are not perceivably different.

Citation
Mottola, R.M. “Blind Listening Evaluation of Classical Guitar Soundports” American Lutherie #96, 2008, p. 54.


What has your experience with soundports been?

If you are a player or luthier please leave a comment below.



11 Comments

  1. I used to play a Lo Prinzi Nova Futura, and found that the ports really opened the sound up. An added bonus was that when playing with ensembles or orchestras the port acted as a natural “stage monitor”, allowing me to hear myself better than I could without them.

  2. I think it would be great if they help you hear your own guitar better. I’ve noticed that when I record the guitar from in front it sounds much better on playback then it does when I’m playing it. Maybe that’s just a characteristic of cheap guitars!

  3. I really appreciate your article on sound ports as I have been curious about them for some time. Personally I would not add a sound port to my concert classical as I would consider the risk of being unhappy with the outcome too great.

    I think I would have to fall in love with a guitar that already had a sound port.

    • I agree Alan, I wouldn’t add a soundport to pre-existing guitar. With the magnetic cover there is little reason to not have it…I figure…

  4. How about we be honest first and admit nearly all of us play for only ourselves. A port makes the player’s experience way better and takes nothing away from an audience. On my very lightly constructed guitar, all listeners confirm a fuller sound with a half inch by three and a half inch port within two inches of the neck. Closeable ports are very easy to construct. With nothing to lose (except in a collectible), why not enjoy playing more?

    • I actually don’t like the sound of my portal open. There are so many strange overtones and everything is too bright and open sounding. Maybe it just because I’ve played without one for twenty odd years… I will say, however, that if I’m in a ‘dead’ sounding room it sure is nice, also when playing with other instruments such as piano it really helps…

  5. our local luthier stated that there is no difference, with sound port on the side, what the audience can hear but additional port at back of the guitar would be beneficial, allowing the air pass more freely through the guitar. Has anyone any experience about this?

  6. It is interesting that players who have played a guitar with a soundport that have commented here are unanimous in saying they hear a louder sound when playing but the one blind study conducted under rigorous control shows the blindfolded players could not perceive (accurately identify) between ported and non-ported guitars or ported guitars with port open or covered.

    There is probably an expectation and belief at play here… not as bad as “the king who has no clothes” but perhaps some overly enthusiastic expectations and desires coloring auditory perception.

    Carruth’s comments indicate a less rigorous testing but with resulted that seemed to indicate only a 1% to 2% yield in increased volume. The ear hears according to a logarithmic scale so a measurable increase in sound volume requires a much larger increase in sound energy or power.

    More rigorous scientific testing could be done but it seems the players like sound ports and believe they make a difference so why not?

    I now someone who has developed a micro Tornavoz which is absolutely impossible in its construction to create the Helmholtz Tornavoz effect but he is convinced it makes a difference based on the Helmholz effect a real Tornavoz would create and no amount of science is going to change his perception. It is true that the micro Tornavoz may be having some sort of influence on the resulting sound but certainly not based on the Helmholtz effect, claims notwithstanding. Physics is pretty darn solid on this. Human perceptions are subjective.

    Sound energy is easy to measure scientifically. The much respected luthier, engineer and scientist R. M. Mottola chose to conduct a player blind test rather than set up scientific est equipment, but the idea was to test the auditory perception of the player. You read the results above.

    Sound is not projected to the audience through the top sound hole, it is projected from the vibration of the top. The sides are quite stiff and a sound port does allow some portion of the sound waves inside the guitar body to leak or bounce out of the sound box (body) but apparently not much per Carruth’s non-specified measurement method cited above and per Mottola’s rigorous blind player perception experiment. Seeing the sound port hole is believing, apparently.

    In the end what counts is pleasing the player and pleasing the audience.

  7. Mike Kennedy on

    My Kenny Hill Signature guitar came with sound ports on either side of the neck. I was surprised by how loud the guitar seemed at first, but after a month I’ve gotten used to it. I find that it makes me aware of the range of volumes I can project. It forced me to play more softly and accurately.

  8. for me soundholes do have a significant impact. that being said, i also believe that the guitar is obviously going to decide if it works or not. already bright guitars prob. dont need a port, but i have installed ports on a couple of my duller sounding acoustics with great results. i have a fellow guitarist roomie who i have play the guitar in almost a blind test, he can hear the positive difference as well. i have experimented quite a bit, and have found that the ‘common’ placement, middle upper bout, is more or less the best place, for me. i have added a two more 1″ ports, one above, and one below the original 1.5″ large hole, and have found the the extra port above the large one adds a tad more clarity, but to me the most significant thing i noticed was when i covered the small port below the larger soundhole, there was a greater bass response. the distance between the 3 soundhole is about .5″. Ray Whitaker is a luthier worth noting who builds in Kasha standard, and his work to me is a great source per soundports.
